Dear Beta tester,

Thank you for taking the time to experience these engineering samples from nami. Built with intelligent sensing technology, use them to monitor your home and care for your loved ones.

We do not want testers to use TestFlight versions anymore, and we would like to push only production versions on App Store and Google Play. We will still keep using TestFlight version but only internally, or in very specific cases.

Before you install the devices, please download the nami Lookout24 app.

The nami Lookout24 app will keep evolving with multiple users, advanced notification alerts, sensitivity settings, remote access via the cloud, and more.

Enjoy monitoring, caring, and surfing through nami waves with our engineering samples. Your feedback and insights are welcome. Loo

nami beta

Useful guides

→ Set up for sample kit of plugs
→ Set up for sample kit for security, with our pod
→ Set up for sample kit of Wi-Fi & Thread
→ FAQ for beta testers

PIR Motion Sensor Angled View
PIR Motion Sensor Front View

PIR Motion Sensor

Thread

General

Dimensions (H x W x D)65.0 × 44.0 × 44.0 mm (2.55 × 1.73 × 1.73 in)
Power RequirementsBattery powered 3VDC, 1 × CR2477
Battery LifetimeUp to 2 years
MaterialPC
LED1 × White Status LED
Button1 × Reset Button
Detection Range6m at 110° field of view

Network

ProtocolIEEE 802.15.4
Wireless TypeThread, Bluetooth 5 (For onboarding)

Operating Conditions

Work Environment-10°C ~ +50°C (14°F ~ 122°F) | 0% ~ 90% R.H.
CertificationsFCC, CE, MIC, UL4200A, ROHS
Safety FeaturesIP20 Dust Protection
Bluetooth and Thread Logo
Keypad Angle View

Keypad

Thread

General

Dimensions (H x W x D)62.0 × 98.0 × 21.8 mm (2.44  × 3.86 × 0.86 in)
Power RequirementsBattery powered, 3× AAA
Battery LifetimeUp to 2 years
MaterialPC
LED1 × White Power Button LED
ButtonsMode, Numeric 0-9, Clear & SOS

Network

ProtocolIEEE 802.15.4
Wireless TypeThread, Bluetooth 5 (For onboarding)

Operating Conditions

Work Environment-10°C ~ +50°C (14°F ~ 122°F) | 0% ~ 90% R.H.
CertificationsFCC, CE, MIC, ROHS
Safety FeaturesIP20 Dust Protection
Bluetooth and Thread Logo
Door Sensor Angle View
Door Sensor Front View

Door Sensor

Thread

General

Dimensions (H x W x D)Sensor: 50.5 × 32.0 × 21.9 mm (1.99 × 1.26 × 0.86 in)
Magnet: 27.0 × 12.0 × 12.4 mm (1.06 × 0.47 × 0.49 in)
Power RequirementsBattery powered 3VDC, 1× CR2477
Battery LifetimeUp to 4 years
MaterialPC
LED1 x White Power Button LED
Button1 x Reset Button
Max Gap Between Sensor & Magnet20mm

Network

ProtocolIEEE 802.15.4
Wireless TypeThread, Bluetooth 5 (For onboarding)

Operating Conditions

Work Environment-10°C ~ +50°C (14°F ~ 122°F) | 0% ~ 90% R.H.
CertificationsFCC, CE, MIC, UL4200A, ROHS
Safety FeaturesIP20 Dust Protection
Bluetooth and Thread Logo
Angle view of SensePlug Type A with Cyan LED
Front view of SensePlug Type A with Cyan LED

SensePlug (Type A)

Wi-Fi + Thread

General

Dimensions (H x W x D)74.7 × 36.1 × 48.8 mm (2.94 × 1.42 × 1.92 in)
Power RequirementsAC 100V~ | 50/60Hz
Maximum Load15A, 1500W | General use, Resistive load
MaterialPC
LED1 × RGB Status LED, 1 x White Power Button LED
Button1 × Power Button

Network

Protocol IEEE 802.11b/g/n, IEEE 802.15.4
Wireless Type Wi-Fi 2.4Ghz, Thread, Bluetooth 5 (For onboarding)

Operating Conditions

Work Environment-10°C ~ +40°C (14°F ~ 104°F) | 0% ~ 90% R.H.
CertificationsPSE, MIC, ROHS
Safety FeaturesIP20 Dust Protection
Class I IEC Electrical Appliance Protection
Wi-Fi, Bluetooth and Thread Logo
Angle view of SensePlug Type B with Cyan LED
Front view of SensePlug Type B with Cyan LED

SensePlug (Type B)

Wi-Fi + Thread

General

Dimensions (H x W x D)2.94 × 1.42 × 1.92 in (74.7 × 36.1 × 48.8 mm)
Power RequirementsAC 120-230V~ | 50/60Hz
Maximum Load15A, 1800W | General use, Resistive load
MaterialPC
LED1 × RGB Status LED, 1 × White Power Button LED
Button1 x Power Button

Network

Protocol IEEE 802.11b/g/n, IEEE 802.15.4
Wireless Type Wi-Fi 2.4Ghz, Thread, Bluetooth 5 (For onboarding)

Operating Conditions

Work Environment 14°F ~ 104°F (-10°C ~ +40°C) | 0% ~ 90% R.H.
CertificationsETL, FCC, ROHS
Safety FeaturesIP20 Dust Protection
Class I IEC Electrical Appliance Protection
Wi-Fi, Bluetooth and Thread Logo
Angle view of SensePlug Type E with Cyan LED
Front view of SensePlug Type E with Cyan LED

SensePlug (Type E)

Wi-Fi + Thread

General

Dimensions (H x W x D)77.2 × 57.2 × 74.7 mm (3.04 × 2.25 × 2.94 in)
Power RequirementsAC 230V~ | 50/60Hz
Maximum Load16A, 3680W | General use, Resistive load
MaterialPC
LED1 × RGB Status LED, 1 × White Power Button LED
Button1 × Power Button

Network

Protocol IEEE 802.11b/g/n, IEEE 802.15.4
Wireless Type Wi-Fi 2.4Ghz, Thread, Bluetooth 5 (For onboarding)

Operating Conditions

Work Environment-10°C ~ +40°C (14°F ~ 104°F) | 0% ~ 90% R.H.
CertificationsCE, ROHS
Safety FeaturesIP20 Dust Protection
Class I IEC Electrical Appliance Protection
Wi-Fi, Bluetooth and Thread Logo
Angle view of SensePlug Type F with Cyan LED
Front view of SensePlug Type F with Cyan LED

SensePlug (Type F)

Wi-Fi + Thread

General

Dimensions (H x W x D)77.2 × 57.2 × 74.7 mm (3.04 × 2.25 × 2.94 in)
Power RequirementsAC 230V~ | 50/60Hz
Maximum Load16A, 3680W | General use, Resistive load
MaterialPC
LED1 × RGB Status LED, 1 × White Power Button LED
Button1 × Power Button

Network

Protocol IEEE 802.11b/g/n, IEEE 802.15.4
Wireless Type Wi-Fi 2.4Ghz, Thread, Bluetooth 5 (For onboarding)

Operating Conditions

Work Environment-10°C ~ +40°C (14°F ~ 104°F) | 0% ~ 90% R.H.
CertificationsCE, ROHS
Safety FeaturesIP20 Dust Protection
Class I IEC Electrical Appliance Protection
Wi-Fi, Bluetooth and Thread Logo
Angle view of SensePlug Type G with Cyan LED
Front view of SensePlug Type G with Cyan LED

SensePlug (Type G)

Wi-Fi + Thread

General

Dimensions (H x W x D)70.0 × 55.0 × 60.2 mm (2.76 × 2.17 × 2.37 in)
Power RequirementsAC 230V~ | 50/60Hz
Maximum Load13A, 2990W | General use, Resistive load
MaterialPC
LED1 × RGB Status LED, 1 × White Power Button LED
Button1 × Power Button

Network

Protocol IEEE 802.11b/g/n, IEEE 802.15.4
Wireless Type Wi-Fi 2.4Ghz, Thread, Bluetooth 5 (For onboarding)

Operating Conditions

Work Environment-10°C ~ +45°C (14°F ~ 113°F) | 0% ~ 90% R.H.
CertificationsCE, UKCA, ROHS
Safety FeaturesIP20 Dust Protection
Class I IEC Electrical Appliance Protection
Wi-Fi, Bluetooth and Thread Logo
Alarm Pod with Cyan LED

Alarm Pod

Wi-Fi + Thread

General

Dimensions (H x W x D)95.0 × 95.0 × 35.0 mm (3.74 × 3.74 × 1.38 in)
Power RequirementsDC 5V | Max 1A
Backup Battery LifetimeUp to 3 hours
Alarm Rating98 dB
MaterialPC
LED1 × RGB Status LED
Button1 × Reset Button

Network

Protocol IEEE 802.11b/g/n, IEEE 802.15.4
Wireless Type Wi-Fi 2.4Ghz, Thread, Bluetooth 5 (For onboarding)

Operating Conditions

Work Environment-10°C ~ +45°C (14°F ~ 113°F) | 0% ~ 90% R.H.
CertificationsCE, FCC, MIC, ROHS
Wi-Fi, Bluetooth and Thread Logo
